Video Widget

The Video widget provides the ability to present custom videos in your dashboard. Use it to show a company or customer video, product demos, or any visual content that helps users better understand your application.

Video widget example

1. Video Behavior​

Video behavior defines how the widget obtains the video URL. It can be one of three types: static, conditional, or dynamic.

Static​

It displays the video from a static URL.
You can store the video in TagoIO’s file system and use the public URL that is cached for faster loading.

Conditional​

Create conditions where each condition has an associated video URL. If the variable linked in the Data From field satisfies this condition, the corresponding video will be displayed. This allows you to show different videos based on device data or other criteria.

Dynamic​

The video URL comes from a variable’s value. The widget reads the current value of the selected variable and uses it as the source for the video.

2. 'Data From' Field​

The conditional and dynamic behavior has a Data from field to set the device and variable that will be used.

  • Normal Dashboards – Select one device from your list of devices and choose the variable that contains the data.
  • Blueprint Dashboards – Add the Blueprint device and input the name of the variable that holds the information.
    When using a Blueprint dashboard, the field may not list variables to pick because it doesn’t know the devices linked to your Blueprint Device.
