Metadata

Metadata is one of the most important concepts when creating dashboards and widgets. Metadata is a piece of information that you can store in the variable payload.

With metadata, it is possible to dynamically change the behavior of the widget and how it displays the variable data. For example, it can change a map pin color or place a heat map bubble in another position, and more.

JSON example

{
  "variable": "current",
  "value": 5.3,
  "unit": "A",
  "metadata": {
    "color": "red",
    "my_application_id": "378392922"
  }
}

Using custom metadata fields

You can define your own metadata fields and use them in your Analysis or Application. Some metadata fields trigger specific widget behaviors or change how the widget displays the data.

info

Metadata has priority over customizations set in the widget edit screen. Some widgets provide an option to change this behavior.

For example, this article uses the color and icon metadata fields in the following JSON payload:

{
  "variable": "temperature",
  "value": 71,
  "metadata": {
    "color": "red",
    "icon": "car"
  }
}

You can use your own icon by placing the SVG file URL in the icon metadata field. For your SVG to be displayed correctly, make sure that it has the property viewBox before using it.

Available Metadata Fields

Field	Description	Widget
background_color	Changes the widget background color. It accepts CSS color keywords or HSL, RGB, and HEX color codes.	Angular, Card, Cylinder, Dial, Grain Bin, Image, Solid, Vu Meter
button_color	Sets a color for the button. It accepts CSS color keywords or HSL, RGB, and HEX color codes.	Push Button, Step Button
chart_color	Changes the chart color. It accepts CSS color keywords or HSL, RGB, and HEX color codes.	Card
color	Sets a color for this variable data. It accepts CSS color keywords or HSL, RGB, and HEX color codes.	Angular, Area Chart, Card, Cylinder, Dial, Dynamic Table, Grain Bin, Horizontal Bar, Icon, Image Marker, Keypad, Line Chart, Map, Multiple Charts, Pie, Semi Donut, Semi Pie, Solid, Static Table, Step Button, Vertical Column, Vu Meter
dropdown_option_hidden	Dynamically hides the option from dropdown fields. Accept true or false	Dynamic Table, Static Table, Device List, User List, Input Form
embed	Sets an embedded URL for the variable display	Compose, Image Marker
end_date	Specifies the end of a date range. It accepts the date and time in the ISO 8601 format.	Area Chart, Horizontal Bar, Line Chart, Multiple Charts, Vertical Column
icon	Specifies an icon for the variable data. It accepts the TagoIO icon's name, and an SVG file URL.	Compose, Icon, Image Marker, Map
img_pin	Sets an image for the infobox. It only accepts image file URLs.	Image Marker, Map
label	Displays a label instead of the variable value	Compose, Dynamic Table, Image Marker, Map, Static Table
layer	Sets the specific layer id that this data is related to	Image Marker
limit_superior	Specifies the end of a scale range. It only accepts numerical values.	Angular, Dial, Cylinder, Grain Bin, Heat Map, Solid, Vu Meter
limit_inferior	Specifies the start of a scale range. It only accepts numerical values.	Angular, Dial, Cylinder, Grain Bin, Heat Map, Solid, Vu Meter
point_color	Sets a color for the chart point (can be replaced by the color field). It accepts CSS color keywords or HSL, RGB, and HEX color codes.	Area Chart, Horizontal Bar, Line Chart, Multiple Charts, Vertical Column
radius	Sets a point radius for charts. It only accepts numerical values, and the default value is 4.	Area Chart, Heat Map, Horizontal Bar, Line Chart, Multiple Charts, Vertical Column
start_date	Specifies the start of a date range. It accepts the date and time in the ISO 8601 format.	Area Chart, Horizontal Bar, Line Chart, Multiple Charts, Vertical Column
text_color	Sets a color for the widget text. It accepts CSS color keywords or HSL, RGB, and HEX color codes.	Angular, Cylinder, Dial, Grain Bin, Push Button, Solid, Vu Meter
url	Shows an external URL	Compose, Dynamic Table, Image Marker, Map, Static Table
url_label	Adds a custom label instead of showing the external URL link	Compose, Image Marker
x	Sets the x coordinate. It only accepts numerical values from 0 to 1.	Compose, Image Marker, Heat Map
y	Sets the y coordinate. It only accepts numerical values from 0 to 1.	Compose, Image Marker, Heat Map

Form Field Metadata

Some widgets such as Input Form, Dynamic Table, and others allow users to edit variable data through form fields. The following metadata can be used for custom behavior in these form fields:

Field	Description	Form field type
label	Displays a label instead of the variable value	Dropdown, Dropdown Multiple, Filtered Variables
end_date	Specifies the end of a date range. It accepts the date and time in the ISO 8601 format.	Calendar
start_date	Specifies the start of a date range. It accepts the date and time in the ISO 8601 format.	Calendar
type	Changes the box validation color. Accepts: "success", "danger", "error", "danger-light", "error-light", "info", "warning" and "dark".	Validation

---
